MTL5544D MTL Intrinsic Safety Isolators

Brand Name : MTL

Model Number : MTL5544D

Place of Origin : England

MOQ : 1

Price : Negotiable

Payment Terms : T/T,Western Union

Supply Ability : 500pcs/month

Delivery Time : 3 working days

Packaging Details : original package

Condition : original brand new

Warranty : one year

Shipping way : DHL FedEx express

Application : Automation Industries, oil, gas, chemical industries

Certificate : CE ISO TUV

Contact Now

MTL5544D MTL Intrinsic Safety Isolators

Eaton Crouse-Hinds series MTL5500 repeater power supply featuring 1 channel analogue input, 20-35 Vdc power supply, and 1.4W dissipation. Designed for 4-20mA signal processing with HART communication support on terminals 1 & 2 (output Channel 1 only). Features green LED power indication and compatibility with 2- or 3-wire transmitters with dual output capability.

Product Specifications

Product Name	Eaton Crouse-Hinds series MTL5500 repeater power supply
Catalog Number	MTL5544D - FSM ASSESSED
EAN	3066227675815
Product Dimensions	109.8 mm (L) × 118.8 mm (H) × 15.8 mm (W)
Product Weight	150 g
Global Catalog	MTL5544D
Product Type	Repeater power supply

Technical Specifications

Type	2- or 3-wire transmitters, dual output
Area Classification	Hazardous/Classified Locations
Standards	IEC, IECEx/ATEX
IECEx/ATEX Hazardous Rating	Zone 0
Operating Temperature	-20 °C to 60 °C
Storage Temperature	-40 °C to 80 °C
Humidity	5-95% relative humidity
Signal Type	Analogue input
Signal Range	4-20mA
Response Time	Settles to within 10% of final value within 50µs
Load Resistance	0-360Ω (at 24mA), 0-450Ω (at 20mA)
Number of Channels	1
Terminal Capacity	Accepts conductors up to 2.5mm² stranded or single-core
Mounting Method	T-section 35mm DIN rail
EMC	EN61326
Ripple	<50µA peak-to-peak
Safety Integrity Level (IEC61508)	SIL2 and SIL3
Communication Support	HART (terminals 1 & 2, output Ch 1 only)
Electrical Connection	Crimp ferrules
Power Supply	20-35 Vdc
Current Consumption	96mA at 24 Vdc
Galvanic Isolation	250V rms between safe-area circuits and power supply
LED Indication	Yes
LED Color - Power	Green
Power Dissipation	1.4W at 24 Vdc
Transfer Accuracy	Better than 15µA
Temperature Drift	<0.8µA/°C
Under/Over Range	0-24mA
